Operations
Operations
4 PARTIAL (*Supported only on PDP-503MXE)
The PARTIAL setting is available only during personal
computer input (1280 x 1024/60 Hz only).
The input signal and the screen maintain a dot to line ratio
of 1:1. Display is highly faithful to the source. However, in
order to maintain the 1:1 ratio, a portion of the display will
not appear on the screen.
Use 5/∞ to adjust the position of the video image on the
screen.
768 lines
1024 lines
Moving the screen position
upward or downward
(*Supported only on PDP-503MXE)
During personal computer input (1280 x 1024/60Hz only),
even when the PARTIAL setting is selected, the position
of the screen can be adjusted by using 5/∞. The
adjustment value will not, however, be stored in memory.
