4.5.4 Stand assembling
1) Assembling Steps
1 Turn the base cover over so that the bottom is facing up.
2 Insert the stand pipes into the base cover.
3 Use the included screws (4 mm × 8 mm) to stabilize the stand pipes.
Note
Assemble the stand with a soft sheet placed under the base cover.
If a sheet is not laid before assembly, the front surface of the base cover may be scratched.
Screws (4 mm × 8 mm)
Base cover
Screws (4 mm × 8 mm)
Stand pipe
Sheet
[507CMX : 427CMX]Table Top Stand: PDK-TS07
