Tilt Mount Unit: PDK-5011
4.6 Tilt Mount Unit: PDK-5011
4.6.1 Specifications
External dimensions ................. 1222 mm (W) × 736 mm (H) × 144 mm (D) (48-1/8 in. (W) × 28-31/32 in. (H) × 5-21/32 in. (D))
(mounting hardware and Plasma Display <PDP-507CMX>)
1022 mm (W) × 610 mm (H) × 143 mm (D) (40-1/4 in. (W) × 24-1/32 in. (H) × 5-5/8 in. (D))
(mounting hardware and Plasma Display <PDP-427CMX>)
Weight ....................................... 13.8 kg (30.4 lbs.) (mounting hardware only)
49.3 kg (108.7 lbs.) (mounting hardware and Plasma Display <PDP-507CMX>)
44.3 kg (97.7 lbs.) (mounting hardware and Plasma Display <PDP-427CMX>)
Materials .................................... General structural steel tubes (STKM-R), SS400, SPHC
Finish.......................................... Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging......... 890 mm (W) × 120 mm (H) × 700 mm (D)
(35-1/32 in. (W) × 4-23/32 in. (H) × 27-9/16 in. (D))
Package weight......................... 18.0 kg
(39.7 lbs.)
Layers of packing ...................... 20 layers
Components
Tilt mount unit ..................................................... × 1
Bolts M8 .............................................................. × 6
Hexagonal wrench .............................................. × 1
For wall-mounting, allow adequate space (a clearance of 300 mm or more) above and below the panel, as well as on the
right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature: 0 °C to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-5011.
✩ Operating temperature restrictions for when the speaker system (PDP-S53-LR, PDP-S56-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
[507CMX : 427CMX]
