Pioneer PDP-507CMX User Manual

236
Integrator Mode
15) OSD Display Setting
This option allows the On-Screen-Display (OSD) menu to appear or to be hidden. OSD menu display features and
location are adjustable.
Factory setting: DISPLAY ........... ON
SIZE ................... LARGE
ANGLE .............. H
1 Enter the integrator mode.
(Refer to section 5.4.1, “About the Integrator Mode” (pg. 214).)
2 Select ‘OPTION’.
3 Place the cursor on ‘OSD’ then press the [SET] button.
7 Setting the Screen display
4 Place the cursor on ‘DISPLAY’ then use the [2/3] buttons
to change the settings.
Each time a [2/3] button is pressed, the setting changes
as shown below.
ON ....... Pressing the MENU button displays the menu.
OFF ..... Even if the MENU button is pressed, the menu
is not displayed.
7 Setting the Screen size
5 Place the cursor on ‘SIZE’ then use the [2/3] buttons to
change the settings.
Each time a [2/3] button is pressed, the setting changes
as shown below.
LARGE ..... The display is doubled horizontally and
vertically.
SMALL ..... The display appears in original size.
D I S PLAY
OSD
S I Z E
ANGLE
RETURN
:
:
:
SET EXIT MENU
LARGE
H
ON
Screen 4
Screen 3
INTEGRATOR INPUT1
ENTER
SCREEN SETUP OPTION
FAN CONTROL
OSD
FRONT I ND I CATOR
COLOR MODE
PRO USE
FRC
:
:
:
:
SET EXIT MENU
AUTO
NORMAL
ON
ON
3
3
ON
OFF 2
2
3
3
LARGE
SMALL
2
2
Screen 5
D I S PLAY
OSD
S I Z E
ANGLE
RETURN
:
:
:
SET EXIT MENU
LARGE
H
ON
