Pioneer PDP-507CMX

200
Menu Mode [Applicable only when a PDA-5003/PDA-5004 is installed]
If it is not displayed correctly when “AUTO” has been set, change the setting of the signal format with reference to
the following table.
7 PC signal
Resolution
V
polarity
H
polarity
V [Hz] H [kHz]
Menu mode
Signal format
Set values
RS232C
Signal format
Set values
Remarks
720x400 - - 70.0 31.5 720x400 TYPE 1
640x480 Neg. Neg. 60.0 31.5 640x480 TYPE 1
848x480 Pos. Pos. 60.0 31.0 848x480 TYPE 3
852x480 - - 60.0 31.7 852x480 TYPE 2
800x600 - - 56.0 35.2 800x600 TYPE 1
1024x768 Neg. Neg. 60.0 48.4 1024x768-1 TYPE 1
1024x768 - - 60.0 49.7 1024x768 TYPE 1
1024x768 - - 70.0 56.5 1024x768-1 TYPE 1
1024x768 - - 75.0 60.0 1024x768 TYPE 1
1280x768 - - 56.0 45.1 1280x768 TYPE 1
1280x768 Neg. Pos. 59.8 48.0 1280x768-1 TYPE 5
1280x768 Pos. Neg. 60.0 47.8 1280x768-2 TYPE 4
1280x768 Pos. Neg. 70.0 56.1 1280x768-1 TYPE 3
1360x768 Pos. Pos. 60.0 47.7 1360x768 TYPE 2
1376x768 Pos. Neg. 59.9 48.3 1376x768 TYPE 3
1280x800 - - 60.0 49.7 1280x800 TYPE 2
1280x854 - - 60.0 53.1 1280x854 TYPE 3
1152x864 - - 60.0 53.7 1152x864 TYPE 4
1152x864 - - 75.0 67.5 1152x864 TYPE 2
1280x1024 Pos. Pos. 60.0 63.9 1280x1024 TYPE 1
1400x1050 Neg. Neg. 59.9 64.1 1400x1050-1 TYPE 2
1680x1050 - - 60.0 65.3 1680x1050 TYPE 7
1920x1080 - - 50.0 56.3 1920x1080 TYPE 3 Only INPUT2 effective.
DVI SETUP is set on the PC.
1920x1080 - - 60.0 67.5 1920x1080 TYPE 9 Only INPUT2 effective.
DVI SETUP is set on the PC.
1600x1200 - - 60.0 75.0 1600x1200 TYPE 5
1920x1200 - - 59.9 74.6 1920x1200 TYPE 3
1920x1200 - - 60.0 74.0 1920x1200RB TYPE 4
7
Video signal
Resolution
V
polarity
H
polarity
V [Hz] H [kHz]
Menu mode
Signal format
Set values
RS232C
Signal format
Set values
Remarks
525p - - 60 31.5 525p TYPE 4
576p - - 50 31.25 576p TYPE 1
750p - - 60 45 750p TYPE 3
1125i (1080i) - - 50 28.13 1125i (1080i) TYPE 2
1125i (1035i) - - 60 33.75 1125i (1035i) TYPE 3
1125i (1080i) - - 60 33.75 1125i (1080i) TYPE 2
1080p - - 50 56.25 1080p TYPE 1
1125p - - 60 67.5 1125p TYPE 8
1250p - - 50 62.5 1250p TYPE 2
