254
Integrator Mode
7 Setting the two screen REPEAT TIMER
• MODE .................... This sets the display mode.
S BY S1 ⇔ S BY S2 ⇔ S BY S3 ⇔ BTM LEFT ⇔ BTM RIGHT ⇔ TOP RIGHT ⇔ TOP LEFT
• WORK TIME .......... The display time is set in a range from one minute to 24 hours.
[When Side-by-side has been set]
• LEFT ....................... The selected signal is displayed on the left side of Side-by-side 1 to 3
• RIGHT .................... The selected signal is displayed on the right side of Side-by-side 1 to 3
[When Picture-in-picture has been set]
• MAIN ..................... The selected signal is displayed on the main screen of Picture-in-picture.
• SUB ........................ The selected signal is displayed on the sub screen of Picture-in-picture.
Note
Perform this operation after turning the setting of DIVIDER in “5.4.3 Adjustments and setting in the Integrator Mode:
11) VIDEO WALL Setting (pg. 228)” to OFF.
7 Setting the Video Wall REPEAT TIMER
• DIVIDER ................. It sets screen division
1 ⇔ 2 x 2 ⇔ 3 x 3
• WORK TIME .......... It sets the display time in a range from one minute to 24 hours.
• INPUT MODE ........ It sets the signal that is displayed
INPUT1 ⇔ INPUT2
Note
• Perform this operation after turning the setting of AUTO ID in “5.4.3 Adjustments and setting in the Integrator
Mode: 11) VIDEO WALL Setting (pg. 228)”.
• The REPEAT TIMER of Video Wall and two screens do not operate simultaneously.
• In the case of VIDEO WALL, only No. 1 is set and all sets are controlled.
To Next Page
