Pioneer PDP-507CMX User Manual

277
RS-232C Adjustment
2) <QPI> Obtaining Integrator/PICTURE information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QPI (fixed)
3 CONTRAST 3 Byte 000 to 255 Note 1)
4 BRIGHTNESS 3 Byte 000 to 255 Note 1)
5 C,DETAIL R (RED) 3 Byte 000 to 060 Note 1)
6 C,DETAIL Y (YELLOW) 3 Byte 000 to 060 Note 1)
7 C,DETAIL G (GREEN) 3 Byte 000 to 060 Note 1)
8 C,DETAIL C (CYAN) 3 Byte 000 to 060 Note 1)
9 C,DETAIL B (BLUE) 3 Byte 000 to 060 Note 1)
10 C,DETAIL M (MAGENTA) 3 Byte 000 to 060 Note 1)
11 H.ENHANCE 3 Byte 000 to 015 Note 1), Note 2)
12 V.ENHANCE 3 Byte 000 to 015 Note 1), Note 2)
13 COLOR 3 Byte 000 to 127 Note 1), Note 3)
14 TINT 3 Byte 000 to 060 Note 1), Note 3)
15 SHARPNESS 3 Byte 000 to 015 Note 1), Note 3)
16 Main input function 3 Byte Same as item 9 of QST commands
17 Main screen size information 1 Byte Same as item 11 of QST commands
18 Check sum 2 Byte
19 ETX 1 Byte 03hex
Note 1) If the signal type is not confirmed, dummy data is output.
Note 2) During video signal input, dummy data is output.
Note 3) During PC signal input, dummy data is output.
3) <QWB> Obtaining integrator/WHITE BALANCE information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QWB (fixed)
3 R.HIGH 3 Byte 000 to 255 Note 1)
4 G.HIGH 3 Byte 000 to 255 Note 1)
5 B.HIGH 3 Byte 000 to 255 Note 1)
6 R.LOW 3 Byte 000 to 255 Note 1)
7 G.LOW 3 Byte 000 to 255 Note 1)
8 B.LOW 3 Byte 000 to 255 Note 1)
9 Main input function 3 Byte Same as item 9 of QST commands
10 Main screen size 1 Byte Same as item 11 of QST commands
11 Check sum 2 Byte
12 ETX 1 Byte 03hex
Note 1) If the signal type is not confirmed, dummy data is output.
4) <QPS> Obtaining integrator/SCREEN information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QPS (fixed)
3 H.POSITION 3 Byte 000 to 255 Note 1)
4 V.POSITION 3 Byte 000 to 255 Note 1)
5 H.SIZE 3 Byte 000 to 064 Note 1)
6 V.SIZE 3 Byte 000 to 064 Note 1)
7 CLOCK 3 Byte 000 to 255 Note 1), Note 2)
8 PHASE 3 Byte 000 to 031 Note 1), Note 2)
9 Main input function 3 Byte Same as item 9 of QST commands
10 Main screen size information 1 Byte Same as item 11 of QST commands
18 Check sum 2 Byte
19 ETX 1 Byte 03hex
Note 1) If the signal type is not confirmed, dummy data is output.
Note 2) During DVI or video input, dummy data is output.
