280
RS-232C Adjustment
9) <QAP> Obtaining machine name
Sequence
Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QAP (fixed)
3 Machine name information 18 Byte 42 inch:
A (North America model): PDP-427CMX********
G (Europe-general model): PDP-42MXE20*******
50 inch:
J (Japan model): PDP-507CMX-JP*****
A (North America model): PDP-507CMX********
G (Europe-general/CKD model): PDP-50MXE20*******
GS (Europe-general/silver model): PDP-50MXE20*******
4 Check sum 2 Byte
5 ETX 1 Byte 03hex
7) <QSU> obtaining the audio status
Sequence
Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QSU (fixed)
3 Main volume 3 Byte 000 to 042
4 Audio mute status 1 Byte 0: OFF 1: ON
5 INPUT1 sub volume 3 Byte 000 to 020
6 INPUT2 sub volume 3 Byte 000 to 020
7 INPUT3 sub volume 3 Byte 000 to 020
8 INPUT4 sub volume 3 Byte 000 to 020
9 INPUT5 sub volume 3 Byte 000 to 020
10 Check sum 2 Byte
11 ETX 1 Byte 03hex
8) <QCI> Obtaining time information
Sequence
Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QCI (fixed)
3 Time information 2 Byte Hour (24 hour system) 00 to 23 Note 1)
2 Byte Minute 00 to 59 Note 1)
2 Byte Second 00 to 59 Note 1)
4 Dummy data 8 Byte
5 Day of week 1 Byte 1: Sunday 2: Monday 3: Tuesday 4: Wednesday
5: Thursday 6: Friday 7: Saturday Note 1)
6 Check sum 2 Byte
7 ETX 1 Byte 03hex
Note 1) During standby and when this command was initially set, the value at the time that power was finally shut off is transmitted.
