CAPACITORS
C 6401 DCH1201
C 6402 CCSSCH150J50
C 6403–6414 CKSSYB103K16
C 6416–6428 CKSSYB104K10
[7038 DDR BLOCK(U)]
SEMICONDUCTORS
IC 6601 LP2995M
IC 6602–6605 EDD2516AKTA-6B
MISCELLANEOUS
L 6601 BTX1039
CAPACITORS
C 6602,6607–6611 CKSSYB103K16
C 6603–6606 CKSSYB104K10
C 6612,6620,6633,6642 CKSSYB471K50
C 6613–6619,6621,6622 CKSSYB103K16
C 6624,6625,6627–6632 CKSSYB103K16
C 6634–6641,6643,6645 CKSSYB103K16
C 6648 CEHVKW331M6R3
C 6649–6651 BCG1059
[DDR REG BLOCK(U)]
RESISTORS
R 6783,6788-6790,6795 RAB4CQ101J
R 6784–6787,6791–6794 RAB4CQ220J
R 6796,6801,6802,6816 RAB4CQ101J
R 6797–6800,6803–6806 RAB4CQ220J
R 6807–6809,6811,6839 RAB4CQ510J
R 6810,6812–6815 RAB4CQ220J
R 6817–6820,6824–6827 RAB4CQ220J
R 6821–6823,6828,6829 RAB4CQ101J
R 6830–6833,6836–6838 RAB4CQ220J
R 6834,6835 RAB4CQ101J
R 6840 RAB4CQ220J
Other Resistors RS1/16SS###J
CAPACITORS
C 6704-6711 CKSSYB103K16
C 6801-6803 DCH1201
[7038 FLASH BLOCK(U)]
SEMICONDUCTORS
IC 6901 TC7WH02FU
IC 6902 AGC1008
IC 6903 BR24L64F-W
Q 6901 2SA1586
Q 6902 UMD2N
Q 6903 2SC4116
D 6902,6903 UDZS4R7(B)
MISCELLANEOUS
L 6901 LCTAW2R2J2520
F 6901-6904 CTF1557
JA 6901 AKN1073
X 6901 BSS1134
CN 6901 BKP1159
RESISTORS
R 6912,6913 RS1/16S3010F
R 6952 RAB4CQ472J
Mark No. Description Part No.
Other Resistors RS1/16SS###J
CAPACITORS
C 6901 DCH1201
C 6902-6908 CCSSCH101J50
C 6909 CKSRYB105K10
C 6911,6916 CCSSCH8R0D50
C 6912,6913 CCSSCH120J50
C 6915,6919 CKSSYB103K16
C 6917,6923,6924 CKSSYB104K10
[DT VDEC BLOCK(U)]
SEMICONDUCTORS
IC 7001 TVP5160PNP
IC 7002 EDS1616AGTA-75-E
Q 7004 2SC4116
MISCELLANEOUS
F 7001–7006 VTF1084
F 7007 ATX1058
X 7001 BSS1119
RESISTORS
R 7001–7003,7009 RAB4CQ101J
R 7004,7005 BCN1072
R 7010–7013 RAB4CQ510J
R 7014 BCN1071
Other Resistors RS1/16SS###J
CAPACITORS
C 7001–7003,7005 DCH1201
C 7006 CKSSYB102K50
C 7014,7015 CCSSCH100D50
C 7016–7054 CKSSYB104K10
[DT AV BLOCK(U)]
SEMICONDUCTORS
IC 7101 PCM1803DB
IC 7102,7104,7107 NJM2068V
IC 7103,7106 NJM2746V
IC 7105 R5520H001B
MISCELLANEOUS
L 7101,7102 BTH1107
L 7103,7104 BTX1042
L 7106 ATH1160
F 7101–7103 VTF1084
JA 7101 VKS1001
CN 7101 AKM1276
RESISTORS
R 7103,7119 RS1/16SS2402F
R 7104,7118 RS1/16SS1002F
R 7107,7109 RAB4CQ103J
R 7110 RAB4CQ101J
R 7144,7145,7151,7152 RS1/16SS3302F
R 7155,7156,7195,7196 RS1/16SS3302F
Other Resistors RS1/16SS###J
CAPACITORS
C 7102,7165,7174,7177 DCH1165
C 7103,7109,7110 DCH1201
C 7107,7108 CKSRYB105K10
C 7111-7114 CCSRCH331J50
C 7115,7117,7119,7120 CKSSYB103K16
Mark No. Description Part No.
