Pioneer PDP-6070PU User Manual

PDP-6071PU
34
1234
1234
C
D
F
A
B
E
C 7116,7118 CKSSYB271K50
C 7122-7124,7130 CCSSCH220J50
C 7125,7131,7148,7154 CKSSYB391K50
C 7127,7128,7150,7151 CCSSCH560J50
C 7132,7133,7155,7156 CKSSYB103K16
C 7135 ACH1421
C 7136,7138,7166,7167 CKSSYB104K10
C 7139,7140,7162,7163 CKSSYB821K50
C 7145-7147,7153 CCSSCH220J50
C 7171-7173 CKSSYB104K10
[DT D_VIDEO BLOCK(U)]
SEMICONDUCTORS
IC 7201 PE5436A
MISCELLANEOUS
L 7201 BTX1042
RESISTORS
R 7202,7207,7208,7211 RAB4CQ0R0J
R 7212,7215 RAB4CQ472J
R 7214,7249 BCN1067
R 7248 RAB4CQ470J
R 7251 RAB4CQ101J
Other Resistors RS1/16SS###J
CAPACITORS
C 7201-7206 CKSSYB104K10
C 7208,7209,7211-7214 CKSSYB102K50
C 7210 CKSSYB471K50
C 7220 DCH1201
[POD BLOCK(U)]
SEMICONDUCTORS
IC 7301 TC74LCX245FTS1
IC 7302 CIMAXSP2L
IC 7303 TC74LCX257FT
IC 7304 TC74LCX244FTS1
IC 7305,7306 TC74LCX373FT
MISCELLANEOUS
F 7301,7302 ATX1058
F 7303 VTF1084
CN 7301,7302 AKM1354
RESISTORS
R 7305,7317,7333-7335 RAB4CQ470J
R 7323,7339,7342 BCN1067
R 7336,7338,7343 RAB4CQ103J
R 7337,7341 RAB4CQ470J
R 7340 RAB4CQ0R0J
R 7344-7346 BCN1067
Other Resistors RS1/16SS###J
CAPACITORS
C 7301-7303,7305 CKSSYB102K50
C 7304 CCSSCH680J50
C 7306-7315,7319,7320 CKSSYB104K10
C 7321-7323 CKSSYB102K50
[POWER_1 BLOCK(U)]
SEMICONDUCTORS
IC 7401 NJM2370U09
IC 7402 NJM2871BF05
IC 7403 MM1563DF
Mark No. Description Part No.
IC 7405,7406,7408 NJM2846DL3-33
IC 7407 NJM2846DL3-18
D 7402-7408 1SS355
MISCELLANEOUS
L 7401,7403 BTX1042
F 7401 VTF1084
RESISTORS
R 7401,7407 RS1/10S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 7401,7403,7406-7408 CKSSYB104K10
C 7405 CKSRYB104K16
C 7409 CKSQYB225K10
C 7412 CKSSYB103K16
C 7413 CKSSYB471K50
C 7415 CEHVKW470M16
C 7416 CEHVKW220M16
C 7417-7420,7423,7424 DCH1201
C 7421 BCG1060
C 7422,7426,7428 CKSRYB105K10
C 7427 BCG1059
C 7429 DCH1201
[POWER_2 BLOCK(U)]
SEMICONDUCTORS
IC 7501 PQ200WNA1ZPH
IC 7502–7505 R1224N102H
IC 7506 PST3628UR
Q 7501,7502 2SA1586
Q 7503–7506 CPH6311
Q 7507 DTC124EUA
Q 7508–7510 RN1901
D 7501–7504 D1FM3
D 7505 1SS355
MISCELLANEOUS
L 7501,7504 ATH1161
L 7502,7503 ATH1192
L 7505,7506 BTX1042
RESISTORS
R 7502-7504 RS1/4S1R5J
R 7505,7506 RS1/4S3R3J
R 7507,7508 RS1/10S271J
R 7511,7538 RS1/16SS2202F
R 7530 RS1/16SS5102F
R 7531 RS1/16SS8201F
R 7532 RS1/16SS9101F
R 7533 RS1/16SS2402F
R 7539 RS1/16SS3302F
R 7550,7565 RS1/16SS5602F
R 7551,7566 RS1/16SS1202F
Other Resistors RS1/16SS###J
CAPACITORS
C 7501,7502 ACH1442
C 7503 CKSSYB104K10
C 7504,7508,7513 CKSSYB103K16
C 7506,7507 CKSSYB102K50
C 7509 CKSSYB332K50
Mark No. Description Part No.
