Pioneer PDP-6070PU User Manual

PDP-6071PU
35
5678
56
7
8
C
D
F
A
B
E
C 7511,7512,7517,7519 CKSRYB105K10
C 7514,7516 CEHVKW101M6R3
C 7518,7520,7521,7524 DCH1201
C 7522,7523,7525,7528 CKSRYB105K10
C 7526,7527,7529,7530 DCH1201
[DSEL BLOCK(U)]
SEMICONDUCTORS
IC 8001 PD6523A
IC 8002 TC74LCX125FT
IC 8003 TC74VCX574FT
MISCELLANEOUS
L 8001,8002 BTX1042
F 8001,8002 VTF1080
>
F 8004 ATX105
X 8001 ASS1194
8001 HEAT SINK B ANH1645
8002 THERMAL SHEET B AEB1417
>
8003 ANTENNA CABLE 50MM ADE1196
RESISTORS
R 8001–8003 ACN1251
R 8004–8006 BCN1071
R 8026,8027 RAB4CQ101J
Other Resistors RS1/16SS###J
CAPACITORS
C 8001 CCSRCH221J50
C 8002 CKSSYB102K50
C 8003,8006–8013 CCSSCH221J50
C 8004 CKSSYF104Z16
C 8005,8014–8025,8027 CKSSYB104K10
C 8026,8028–8030 DCH1201
[IP BLOCK(U)]
SEMICONDUCTORS
IC 8101 PE5504B
IC 8102,8103 EDS6432AFTA-75-E
MISCELLANEOUS
L 8101-8104 BTX1042
F 8101 ATX1058
RESISTORS
R 8101-8104,8106-8110 BCN1067
R 8105 BCN1071
R 8111,8116 ACN1246
R 8112-8115,8117 ACN1251
R 8123 RAB4CQ103J
R 8135 RAB4CQ470J
R 8136 RAB4CQ101J
Other Resistors RS1/16SS###J
CAPACITORS
C 8101 CKSSYB102K50
C 8102,8126 DCH1201
C 8103-8106,8108-8111 CCSSCH221J50
C 8107,8112-8120 CKSSYB104K10
C 8121-8125,8127-8129 CCSSCH221J50
C 8134-8147 CKSSYB104K10
[MULTI BLOCK(U)]
Mark No. Description Part No.
SEMICONDUCTORS
IC 8201 PEG121B
IC 8202 AGC1007
IC 8203 TC74VHC08FTS1
MISCELLANEOUS
L 8201-8204 BTX1042
RESISTORS
R 8201-8205 ACN1246
R 8206-8208,8255 ACN1251
R 8214,8215,8248 RAB4CQ103J
R 8225,8245 BCN1071
R 8246 BCN1073
R 8249 RAB4CQ680J
R 8250 RS1/10S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 8202 CKSSYB102K50
C 8203-8206,8221-8234 CKSSYB104K10
C 8207,8240-8242 DCH1201
C 8208-8220 CCSSCH221J50
C 8235 BCG1059
C 8239 CKSSYB104K10
[IF UCOM BLOCK(U)]
SEMICONDUCTORS
IC 8301 AGC1016
IC 8302 PST9230N
IC 8303 TC74VHC08FTS1
IC 8304 TC7W126FU
IC 8305 TC74VHC00FTS1
IC 8306 MAX3232CPW
IC 8307 TC74VHC125FTS1
Q 8303-8305 DTC124EUA
Q 8306,8307 2SA1586
D 8301-8304 1SS355
MISCELLANEOUS
X 8301 ASS1168
X 8302 ASS1172
CN 8301 AKP1213
RESISTORS
R 8322 RAB4CQ473J
R 8348-8352 RAB4CQ103J
Other Resistors RS1/16SS###J
CAPACITORS
C 8301 CKSSYB472K25
C 8302,8303 CCSSCH220J50
C 8305,8321 CKSSYB471K50
C 8306-8311,8314-8320 CKSSYB104K10
C 8312,8313 DCH1201
[MAIN UCOM BLOCK(U)]
SEMICONDUCTORS
IC 8401 MB91305PMC-G-BND
IC 8402 AGC1006
IC 8403 PST3628UR
IC 8407 PQ200WNA1ZPH
IC 8409 BR24L64F-W
IC 8410,8411 TC74VHC125FTS1
Mark No. Description Part No.
