D9 : CN505 (AKM1348) X1: CN1001 (AKM1348)
60 DIGITAL ASSY
60 X DRIVE ASSY
Pin No. Name Voltage [V] Name Pin No. Function TP
1 XDD_PD 0 XDD_PD 40 X DRIVE PD signal input TP3513
2NC-NC 39 Non-connection termial
3 DGND 0 DGND 38 GND
4 XSUS-B 0 to 3.3 XSUS-B 37 X DRIVE control signal output
5 DGND 0 DGND 36 GND
6 XSUS-U 0 to 3.3 XSUS-U 35 X DRIVE control signal output
7 DGND 0 DGND 34 GND
8 XSUS-D 0 to 3.3 XSUS-D 33 X DRIVE control signal output
9 DGND 0 DGND 32 GND
10 XSUS-G 0 to 3.3 XSUS-G 31 X DRIVE control signal output
11 DGND 0 DGND 30 GND
12 XNR-D 0 to 3.3 XNR-D 29 X DRIVE control signal output
13 DGND 0 DGND 28 GND
14 XSUS-MSK 0 to 3.3 XSUS-MSK 27 X DRIVE control signal output
15 DGND 0 DGND 26 GND
16 SUS_MUTE 0 SUS_MUTE 25 X DRIVE mute signal input
17 DGND 0 DGND 24 GND
18 XDRV_PD 0 XDRV_PD 23 X DRIVE PD signal input TP3514
19 DGND 0 DGND 22 GND
20 XResv2 - XResv2 21 X DRIVE control signal output (Reserve)
21 XResv3 - XResv3 20 X DRIVE control signal output (Reserve)
22 XResv4 - XResv4 19 X DRIVE control signal output (Reserve)
23 DGND 0 DGND 18 GND
24 PSW2 0 PSW2 17 Function standby control signal TP3516
25 NC - NC 16 Non-connection termial
26 NC - NC 15 Non-connection termial
27 NC - NC 14 Non-connection termial
28 NC - NC 13 Non-connection termial
29 NC - NC 12 Non-connection termial
30 NC - NC 11 Non-connection termial
31 NC - NC 10 Non-connection termial
32 NC - NC 9 Non-connection termial
33 NC - NC 8 Non-connection termial
34 NC - NC 7 Non-connection termial
35 NC - NC 6 Non-connection termial
36 NC - NC 5 Non-connection termial
37 NC - NC 4 Non-connection termial
38 DRF_SW 3.3 DRF_SW 3 DRIVE OFF signal input TP3623
39 NC - NC 2 Non-connection termial
40 XSUS_PD 0 XSUS_PD 1 X DRIVE PD signal input TP3515
To Next Page
