Pioneer PDP-6070PU User Manual

PDP-6071PU
78
1234
1234
C
D
F
A
B
E
D10 : CN3506 (AKM1348) Y1: CN2001 (AKM1348)
60 DIGITAL ASSY
60 Y DRIVE ASSY
Pin No. Name Voltage [V] Name Pin No. Function
1 SCN5V_PD 0 SCN5V_PD 40 Y DRIVE PD signal input TP3507
2NC-NC 39 Non-connection termial
3 CLK_H 0 to 3.3 CLK1 38 SCAN control signal output
4 SI_H 0 to 3.3 SI_H 37 SCAN control signal output
5 SI_L 0 to 3.3 SI_L 36 SCAN control signal output
6 DGND 0 DGND 35 GND
7 CLR 0 to 3.3 CLR 34 SCAN control signal output
8 CLK_L 0 to 3.3 CLK2 33 SCAN control signal output
9 DGND 0 DGND 32 GND
10 LE 0 to 3.3 LE 31 SCAN control signal output
11 OC2_U 0 to 3.3 OC2_U 30 SCAN control signal output
12 OC1(-1) 0 to 3.3 OC1 29 SCAN control signal output
13 DGND 0 DGND 28 GND
14 YSUS-B 0 to 3.3 YSUS-B 27 Y DRIVE control signal output
15 YSUS-U 0 to 3.3 YSUS-U 26 Y DRIVE control signal output
16 DGND 0 DGND 25 GND
17 YSUS-D 0 to 3.3 YSUS-D 24 Y DRIVE control signal output
18 YSUS-G 0 to 3.3 YSUS-G 23 Y DRIVE control signal output
19 DGND 0 DGND 22 GND
20 YPR-U 0 to 3.3 YPR-U 21 Y DRIVE control signal output TP3508
21 SUS_MUTE 0 SUS_MUTE 20 Y DRIVE mute signal output
22 DGND 0 DGND 19 GND
23 YSUS-MSK 0 to 3.3 YSUS-MSK 18 Y DRIVE control signal output
24 YNRST 0 to 3.3 YNRST 17 Y DRIVE control signal output
25 YRSV2 - YRSV2 16 Y DRIVE control signal output (Reserve)
26 DGND 0 DGND 15 GND
27 YENOFS 0 to 3.3 YNOFS 14 Y DRIVE control signal output
28 YRSV3 - YRSV3 13 Y DRIVE control signal output (Reserve)
29 YSOFT-D 0 to 3.3 YSOFT-D 12 Y DRIVE control signal output
30 OC2_D 0 to 3.3 OC2_D 11 SCAN control signal output
31 DGND 0 DGND 10 GND
32 VOFS_ADJ 1.85 VOFS_ADJ 9 Vofs offset adjustment signal output TP3181
33 VYPRST_ADJ 1.21 VYPRST_ADJ 8 Reset voltage adjustment signal output TP3182
34 DGND 0 DGND 7 GND
35 PSW2 0 PSW2 6 Function standby control signal TP3516
36 SCAN_PD 0 SCAN_PD 5 Y DRIVE PD signal input TP3509
37 YDD_PD 0 YDD_PD 4 Y DRIVE PD signlal input TP3510
38 YSUS_PD 0 YSUS_PD 3 Y DRIVE PD signlal input TP3511
39 NC - NC 2 Non-connection termial
40 YDRV_PD 0 YDRV_PD 1 Y DRIVE PD signal input TP3512
