PDP-6071PU
80
1234
1234
C
D
F
A
B
E
Y3: CN2401 (AKM1200) SA1: CN2801 (AKP1261)
60 Y DRIVE ASSY
607 SCAN A ASSY
Pin No. Name Voltage [V] Name Pin No. Function
1 VH 130 VH 1 Power supply for VH
2 VH 130 VH 2 Power supply for VH
3 NC - NC 3 Non-connection termial
4 NC - NC 4 Non-connection termial
5 NC - NC 5 Non-connection termial
6 GNDH -60 300 GNDH 6 GND(PSUS)
7 SI_L -60 300 SI_L 7 SI_L signal
8 CLR -60 300 CLR 8 CLR signal
9 OC2 -60 300 OC2 9 OC2 signal
10 OC1 -60 300 OC1 10 OC1 signal
11 CLK2 -60 300 CLK2 11 CLK2 signal
12 LE -60 300 LE 12 LE signal
13 GNDH -60 300 GNDH 13 GND(PSUS)
14 GNDH_R -60 300 GNDH_R 14 GND(PSUS).Connector detection
15 IC5V -60 300 IC5V 15 IC5V power supply
Y4: CN2351 (B9B-EH) P1: (B9B-EH)
60 Y DRIVE ASSY
POWER SUPPLY UNIT
Pin No. Name Voltage [V] Name Pin No. Function
1NC - NC 1 Non-connection termial
2 +16_5V 16.5 +16_5V 2 16.5V power supply
3 +6_5V 6.5 +6_5V 3 6.5V power supply
4 GND_D 0 GND_D 4 GND
5 GND_SUS 0 GND_SUS 5 GND
6 GND_SUS 0 GND_SUS 6 GND
7 NC - NC 7 Non-connection termial
8 VSUS 207 VSUS 8 VSUS power supply
9 VSUS 207 VSUS 9 VSUS power supply
Y5 : CN2353 (AKM1277) P7: (B7B-PH-K-S)
60 Y DRIVE ASSY
POWER SUPPLY UNIT
Pin No. Name Voltage [V] Name Pin No. Function
1 +60V 60 +60V 1 60V power supply
2 +60V 60 +60V 2 60V power supply
3 NC - NC 3 Non-connection termial
4 GND_ADR 0 GND_ADR 4 GND
5 +12V 12 +12V 5 12V power supply
6 GND_D 0 GND_D 6 GND
NC 7 Non-connection termial
X2: (CN1206 B8B-EH) P2: (B8B-EH)
60 X DRIVE ASSY
POWER SUPPLY UNIT
Pin No. Name Voltage [V] Name Pin No. Function
1 +16_5V 16.5 +16_5V 1 16.5V power supply
2 +6_5V 6.5 +6_5V 2 6.5V power supply
3 GND_D 0 GND_D 3 GND
4 GND_SUS 0 GND_SUS 4 GND
5 GND_SUS 0 GND_SUS 5 GND
6 NC - NC 6 Non-connection termial
7 VSUS 207 VSUS 7 VSUS power supply
8 VSUS 207 VSUS 8 VSUS power supply
To Next Page
