PDP-6071PU

5678

X5: CN1204 (AKM1277) P6: (B6B-PH-K-S)

60 X DRIVE ASSY

POWER SUPPLY UNIT

Pin No. Name Voltage [V] Name Pin No. Function

1 +60V 60 +60V 1 60V power supply

2 +60V 60 +60V 2 60V power supply

3NC - NC 3 Non-connection termial

4 GND_ADR 0 GND_ADR 4 GND

5 +12V 12 +12V 5 12V power supply

6 GND_D 0 GND_D 6 GND

X3: CN1201 (AKM1281) AD2: CN1601 (AKM1291)

60 X DRIVE ASSY

60 ADDRESS L/S ASSY

X6: CN1203 (AKM1281) AD2: CN1801 (AKM1291)

Pin No. Name Voltage [V] Name Pin No. Function

1 GND_D 0 GND_D 1 GND

2 5V 5 5V 2 5V power supply

3 8V 8 8V 3 8V power supply

4 GND_ADR 0 GND_ADR 4 GND

5 +60V 60 +60V 5 60V power supply

6 +60V 60 +60V 1 60V power supply

7 GND_ADR 0 GND_ADR 2 GND

8 8V 8 8V 3 8V power supply

95V55V 4 5V power supply

10 GND_D 0 GND_D 5 GND

AUDIO ASSY CN3752 (A2) ↔ MAIN ASSY CN4007 (M9)

AUDIO ASSY CN3753 (A3) ↔ SP TERMINAL ASSY CN3901 (SP1)

AUDIO ASSY CN3751 (A1) ↔ POWER SUPPLY UNIT (P5)

Pin No. Pin Name I/O Function Remarks

1 A_NG_B O DC detection, disconnection of cable detection L : Abnormal, H : Normal

2 GND – GND for small signal –

3 AUDIO_L I Small signal L ch –

4 GND – GND for small signal –

5 AUDIO_R I Small signal R ch –

6 GND – GND for small signal –

7 A_STBY_B I MUTE ON/OFF signal for LA4625 IC internal circuit L : Standby, H : ON

8 A_MUTE I MUTE ON/OFF signal for LA4625 IC external circuit L : MUTE OFF, H : MUTE

9 SCL_AU I CLK of I2C for NJW1183GK1 IC –

10 SDA_AU I/O DATA of I2C for NJW1183GK1 IC –

11 PSW_A I ON/OFF switch for 12 V regulator IC L : OFF, H : ON

Pin No. Pin Name I/O Function Remarks

1 +16.5V – Power supply (16.5 V) for LA4625 IC –

2 GND_D – Return GND for LA4625 IC –

3 GND_D – Return GND for LA4625 IC –

Pin No. Pin Name I/O Function Remarks

1 RH+ O Tweeter output R+ –

2 RL+ O Woofer output R+ (Speaker output R+) –

3 RH– O Tweeter output R– –

4 RL– O Woofer output R– (Speaker output R–) –

5 LL+ O Woofer output L+ (Speaker output L+) –

6 LH+ O Tweeter output L+ –

7 LL– O Woofer output L– (Speaker output L–) –

8 LH– O Tweeter output L– –
