PDP-6071PU

1234

SIDE KEY ASSY CN9501 (SW1) ↔ MAIN ASSY CN4010 (M8)

Pin No. Pin Name I/O Function Remarks

1 GND – GND –

2 KEY_AD2 O KEY voltage 2 –

3 KEY_AD1 O KEY voltage 1 –

4 V+3.3V_STB – Standby 3.3 V power supply –

60 IR ASSY CN9801 (RE1) ↔ MAIN ASSY CN4010 (M8)

Pin No. Pin Name I/O Function Remarks

1 V+5.1V_STB – Standby 5.1 V power supply –

2 REM O Remote control signal –

3NC – – –

4NC – – –

5NC – – –

6 GND – GND –

42 & 60 LED ASSY CN9601(L1) ↔ MAIN ASSY CN4006 (M5)

Pin No. Pin Name I/O Function Remarks

4 LED_REC I LED control for REC –

5 LED_MDM I – –

6 LED– – LED control for standby –

1 LED– – LED signal return –

2 LED_ON I LED control for power ON H : LED_ON, L : LED_OFF

3 LED_OFF I LED control for standby H : LED_ON, L : LED_OFF
