Integrator Mode
5.4.3 Adjustment and Setting in the Integrator Mode
For details about button controls, refer to section 5.4.2, “Example of Integrator Mode Operation” (pg. 124).
1) PICTURE Adjustment
The adjustable items shown below are a little different than in the menu mode’s PICTURE adjustment (refer to the
instruction manual).
• PC input
CONTRAST, BRIGHTNESS, H. ENHANCE, V. ENHANCE, etc.
• Video input
CONTRAST, BRIGHTNESS, COLOR, TINT, SHARPNESS, etc.
For details, refer to section 5.1.4, “List of Adjustable and Settable Items” (pg. 88).
1 After switching to the input (INPUT1 to INPUT5) to be
adjusted, enter the integrator mode.
Select ‘PICTURE’.
2 Perform adjustment.
Note
When there is PC signal input at INPUT1, 2, and 5,
‘COLOR’, ‘TINT’ and ‘SHARPNESS’ are unavailable.
When there is video input, ‘H. ENHANCE’ and ‘V.
ENHANCE’ are unavailable.
Use the [5/∞] buttons on the remote control or the main-
control panel.
Perform adjustment using the [2/3] buttons on the remote
control or the main-control panel to change settings.
It is possible to move to another item for adjustment using
the [5/∞] buttons.
The value adjusted here becomes the center value for adjustment in the menu mode.
Press the [SET] button to return to screen 1-
1 or screen 2-2.
For details about the adjustable range, refer to section 5.1.4, “List of Adjustable and Settable Items” (pg. 88).
INTEGRATOR INPUT1
ENTER
SCREEN SETUP OPTIONPICTURE
SET
EXIT
MENU
: 2.0
: 12 8
: 0
: 0
: 12 8CONTRAST
BR I GHTNESS
H . ENHANCE
V . ENHANCE
G AMMA
P I CTURE RESET
WH I T E BALANCE
C OLOR DETA I L
Screen 1-1
For PC signal input
For video signal input
(Applicable only when a PDA-5003/PDA-5004 is installed.)
INTEGRATOR INPUT1
ENTER
SCREEN SETUP OPTION
CONTRAST
T I NT
S HARPNESS
0
:
0
:
0
:
23
:
:
0
:
SET
EXIT
MENU
B R I GHTNESS
G AMMA
P I CT URE RESET
WH I TE BALANCE
COLOR DETA I L
COLOR
2.0
:
SET SET EXITMENU
0
BRIGHTNESS
Screen 2
To Next Page
