Pioneer PDP-60MXE20 User Manual

6
Power requirements ........... AC 100 V to 120 V, 50 Hz/60 Hz
(The power unit range is from AC100 V to 240 V (50 Hz/60 Hz))
In-rush ............................................................... less than 50 A
Power factor .................................................... more than 0.95
Consumption ......................... 360 W
(NOTE 2)
(1.5 W in standby)
External dimensions
......................... 1470 mm (W) × 880 mm (H) × 122 mm (D)
57-7/8 in. (W) × 34-21/32 in. (H) × 4-26/32 in. (D)
Weight ........................................................ 62.0 kg (136.7 lbs.)
Dimensions of packaging
....................... 1593 mm (W) × 1022 mm (H) × 434 mm (D)
62-23/32 in. (W) × 40-1/4 in. (H) × 17-3/32 in. (D)
Weight when packaged ............................ 76.3 kg (168.2 lbs.)
Operating Temperature .... 0 °C to 40 °C (32 °F to 104 °F)
(NOTE 3)
Operating Humidity .......................................... 20 % to 80 %
Operating atmospheric pressure .......... 800 hPa to 1100 hPa
Storage limitations (when installed)
Temperature .................. –20 °C to +60 °C (–4 °F to 140 °F)
Humidity ......................................................... 20 % to 90 %
Atmospheric pressure ......................... 700 hPa to 1114 hPa
Storage limitations (when in original package)
Temperature ................ –30 °C to +60 °C (–22 °F to 140 °F)
Humidity ......................................................... 20 % to 90 %
Atmospheric pressure ......................... 700 hPa to 1114 hPa
Stacking .............................................. Fewer than two tiers
Standard accessories
Power cord (2 m) .................................................................... 1
Ferrite core (for audio cables) ................................................. 3
Remote control unit ................................................................ 1
AA battery ............................................................................... 2
Wiping cloth (for screen) ......................................................... 1
Speed clamp ........................................................................... 3
Bead band ............................................................................... 3
Operating instructions ............................................................. 1
Warranty ................................................................................. 1
Specifications and external designs are subject to change without
notice.
(NOTE 1) The display is preset at the factory to 9600bps. This
setting can be changed using either the remote control
unit or a PC.
(NOTE 2) Allow for 500 W = 500 VA of consumption per unit.
(NOTE 3) The correct operating environmental temperature may
vary depending on the installation site (refer to
“Installation Site Requirements (pg. 16)”.
2.1 Specifications
Light-emitting panel ..................... 60V type AC Plasma Panel
131.86 cm (W) × 74.19 cm (H) × 151.3 cm (diagonal)
Aspect ratio .................................................................... 16 : 9
Pixels ...................................................................... 1365 × 768
Pixel pitch ................. 0.966 mm (H•RGB trio) × 0.966 mm (V)
Input/output terminals
Video-related
INPUT 1
Input Mini D-sub, 15-pin connector (female)
• RGB signal (for SYNC ON G)
RGB ............................... 0.7 Vp-p/75 Ω/no sync
HD/VS, VD ........ TTL level/positive and negative
polarity/2.2 kΩ
SYNC ON G ............ 1 Vp-p/75 Ω/negative sync.
*Microsoft Plug & Play (VESA DDC 1/2B) supported
Output Mini D-sub, 15-pin connector (female)
.................................. 75 Ω/with buffer
INPUT 2
Input DVI-D 24-pin connector
Digital RGB signal (DVI compliant TMDS signal)
*Microsoft Plug & Play (VESA DDC 2B) supported
Audio-related
Input AUDIO INPUT (for INPUT1)
Stero mini jack
L/R ...................... 500 mVrms/more than 10 kΩ
AUDIO INPUT (for INPUT2)
Stero mini jack
L/R ...................... 500 mVrms/more than 10 kΩ
Output AUDIO OUTPUT
Stero mini jack
L/R .......................... 500 mVrms/less than 5 kΩ
SPEAKER
L/R ................... 6 Ω to 16 Ω/9 W + 9 W (at 6 Ω)
Control-related
RS-232C terminal: D-sub, 9-pin (male)
(NOTE 1)
Combination In/Out Terminal: Mini-DIN, 6-pin
Specifications

Pioneer PDP-60MXE20 Specifications

General

Depth	122 mm
Width	1470 mm
Height	880 mm
Weight	62000 g
Pixel pitch	0.966 x 0.966 mm
Product color	Black
Audio (L/R) out	1
Noise reduction	Yes
Display diagonal	60 \
Display brightness	1000 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Power requirements	AC 100 - 240 V, 50/60 Hz
Viewing angle, horizontal	160 °
Display viewable area (HxV)	1318.6 x 741.9 mm
Operating temperature (T-T)	0 - 40 °C
Power consumption (standby)	0.8 W
Power consumption (typical)	450 W
Operating relative humidity (H-H)	20 - 80 %
