Pioneer PDP-60MXE20 User Manual

175
RS-232C Adjustment
Command
434CMX
505CMX
Command
425CMX
Command
60MXE20
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
MSTS06
++
Sets the MULTI SCREEN to PoutP (side by side, 2-L).

– MSTS08
+
Sets MULTI SCREEN to SWAP (switches between main
and sub screens).

– MSTS09
+
Sets MULTI SCREEN to PoutP (side by side 2-R).

–
MSTS10
+
Sets MULTI SCREEN to 2-SCREEN (side by side 3).

–
MSTS11
+
Sets MULTI SCREEN to PoutP (side by side 4-L).

– MSTS12
+
Sets MULTI SCREEN to PoutP (side by side 4-R).

SSI
+
+
Displays the present input to the SUB Screen.
FUNCTIONAL LOCK
FCL
++
Displays the present set value of the FUNCTIONAL LOCK.
FCLS00
++
Cancels FUNCTIONAL LOCK.

FCLS01
++
Prohibits operation of buttons on the display.

FCLS02
++
Prohibits operation of buttons on the remote control.

FCLS03
++
Prohibits operation of buttons on the display/remote control.

FCLS04
++
Sets the memory lock

OSD
DOF
++
Turns off the OSD display that is now displayed.
7
“MENU”–“SETUP” related commands
Command
434CMX
505CMX
Command
425CMX
Command
60MXE20
Function
Number direct
Last
memory
Comment
Effective Minimum Maximum
COLOR TEMP.
CTP
++
Displays the present set value of the color temperature.
CTPS01
++
Sets the color temperature to LOW.

CTPS02
++
Sets the color temperature to MID LOW.

CTPS03
++
Sets the color temperature to MIDDLE.

CTPS04
++
Sets the color temperature to MID HIGH.

CTPS05
++
Sets the color temperature to HIGH.

DNR
DNR
++
Displays the present set value of the DNR.
DNRS00
++
Sets digital NR to OFF.

DNRS01
++
Sets digital NR to LOW.

DNRS02
++
Sets digital NR to MIDDLE.

DNRS03
++
Sets digital NR to HIGH.

MPEG NR
MNR
++
Displays the present set value of the MPEG NR.
MNRS00
++
Sets MPEG NR to OFF.

MNRS01
++
Sets MPEG NR to LOW.

MNRS02
++
Sets MPEG NR to MIDDLE.

MNRS03
++
Sets MPEG NR to HIGH.

CTI
CTR
++
Displays the present set value of CTI.
CTRS00
++
Sets CTI to OFF.

CTRS01
++
Sets CTI to ON.

PURE CINEMA
PUC
++
Displays the present set value of PURE CINEMA.
PUCS00
++
Sets PURE CINEMA to OFF.

PUCS01
++
Sets PURE CINEMA to STANDARD.

COLOR DECORDING
MCD
++
Displays the present color decoding.
MCDS01
++
Sets COLOR DECORDING to RGB (VIDEO).

MCDS02
++
Sets COLOR DECORDING to COMPONENT1 (YCbCr).

MCDS03
++
Sets COLOR DECORDING to COMPONENT2 (YPbPr).

COLOR SYSTEM
CLS
++
Displays the present set value of the color system.
CLSS01
++
Sets color system to AUTO.

CLSS02
++
Sets color system to NTSC.

CLSS03
++
Sets color system to PAL.

CLSS04
++
Sets color system to SECAM.


Pioneer PDP-60MXE20 Specifications

General

Depth	122 mm
Width	1470 mm
Height	880 mm
Weight	62000 g
Pixel pitch	0.966 x 0.966 mm
Product color	Black
Audio (L/R) out	1
Noise reduction	Yes
Display diagonal	60 \
Display brightness	1000 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Power requirements	AC 100 - 240 V, 50/60 Hz
Viewing angle, horizontal	160 °
Display viewable area (HxV)	1318.6 x 741.9 mm
Operating temperature (T-T)	0 - 40 °C
Power consumption (standby)	0.8 W
Power consumption (typical)	450 W
Operating relative humidity (H-H)	20 - 80 %
