Pioneer SC430 - CASSETTE MECHANISM MODULE SECTION PARTS LIST

11
FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
- CASSETTE MECHANISM MODULE SECTION PARTS LIST
1 Screw BSZ20P040FMC
2 Washer CBF1037
3 Washer CBF1038
4 Washer CBG1003
5 Deck Unit EWM1030
6 Screw(M2x5) EBA1028
7 Screw(M2x2.5) CBA1037
8 Spring EBH1531
9 Spring EBH1589
10 Connector(CN251) CKS3540
11 Spring EBH1515
12 Spring EBH1587
13 Spring EBH1517
14 Spring EBH1518
15 Spring EBH1519
16 Spring EBH1537
17 Cord EDD1027
18 Photo-interrupter
(EGN2,3) EGN1006
19 Photo-interrupter(EGN1) EGN1005
20 Roller ENR1031
21 Shaft ELA1362
22 Roller ELA1348
23 Arm ENC1490
24 Arm ENC1397
25 Guide ENC1519
26 Holder ENC1516
27 Lever ENC1448
28 Arm ENC1488
29 Roller ENR1023
30 Belt ENT1027
31 Gear ENV1347
32 Collar ENV1508
33 Gear ENV1350
34 Flywheel ENV1500
35 Worm Gear ENV1439
36 Worm Wheel ENV1440
37 Gear ENR1037
38 Lever ENV1533
39 Arm ENV1525
40 Gathering PCB ENX1037
41 Gathering PCB ENX1060
42 Switch(S1)(S2) ESG1004
43 Motor Unit(M2)(SUB) EXA1382
44 Chassis Unit EXA1559
45 Tube ENM1039
46 Roller ENR1027
47 Reel Unit EXA1560
48 Head Base Unit EXA1434
49 Lever Unit EXA1578
50 Gear Unit EXA1545
51 Frame Unit EXA1476
52 Lever Unit EXA1439
53 Head Assy(HD1) EXA1594
54 Motor Unit(M1)(MAIN) EXA1499
55 Washer HBF-179
56 Screw JGZ20P025FNI
57 Spring EBH1545
58 Washer YE20FUC
59 Pinch Roller Unit EXA1533
60 Pinch Roller Unit EXA1532
61 Capacitor(C1) CEAL4R7M35
Mark No. Description Part No. Mark No. Description Part No.
