Pioneer SC430 - EXTERIOR SECTION PARTS LIST

5
FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
1 Screw BMZ26P040FMC
2 Screw BMZ30P050FMC
3 Connector CDE6448
4 Connector CDE6509
5 Chassis CNA2257
6 Frame CNC8700
7 Insulator CNM6650
8 Seal CNM7286
9 Label CRW1417
10 Main Unit CWM7047
11 Screw BMZ30P060FMC
12 Screw(M3x6) CBA1393
13 Terminal(CN800) CKF1059
14 Plug(CN803) CKM1221
15 Connector(CN802) CKM1315
16 Connector(CN801) CKM1322
17 Plug(CN300) CKS-291
18 Connector(CN301) CKS3568
19 Connector(CN804) CKS4361
20 Connector(CN303) CKS4376
21 86146-48030(ANT1) CKX1057
22 86146-48040(ANT2) CKX1058
23 Holder CNC8704
24 FM/AM Tuner Unit CWE1591
25 Holder CNC6122
26 Control Unit CWM7280
27 Terminal(CN703) CKF1064
28 Connector(CN701) CKS3989
29 Connector(CN702) CKS4376
30 Screw BPZ20P080FMC
31 Button(AF,PTY) CAC6479
32 Button(SEEK,TRACK) CAC6465
33 Button(TXT,AST) CAC6480
34 Button(1,2) CAC6467
35 Button(3,4) CAC6468
36 Button(5,6) CAC6469
37 Button(DISC) CAC7170
38 Button(TAPE) CAC7169
39 Button(FM) CAC7168
40 Button(AM) CAC7167
41 Button(TA) CAC6483
42 Button(CD EJECT) CAC6482
43 Button(TAPE EJECT) CAC6478
44 Button(LOAD) CAC6481
45 Door
See Contrast table(2)
46 Spring CBH2435
47 Seal CNM7027
48 Seal CNM7028
49 Holder CNV6106
50 Holder CNV6107
51 Lighting Conductor CNV6108
52 Lighting Conductor CNV6109
53 Lighting Conductor CNV6118
54 Rubber CNV6119
55 Lighting Conductor CNV6126
56 Lighting Conductor CNV6351
57 Keyboard Unit CWS1333
58 LCD(LCD901) CAW1691
59 Connector(CN902) CKS4361
60 Holder CNC8672
61 Sheet CNM6620
62 Lighting Conductor CNV6114
63 Connector CNV6115
64 Knob Unit
See Contrast table(2)
65 Grille Unit See Contrast table(2)
66 Screw BMZ20P080FMC
67 Door CAT2221
68 Washer CBF1037
69 Spring CBH2446
70 Lighting Conductor CNV6110
71 Lighting Conductor CNV6111
72 Holder CNV6590
73 Gear CNV6726
74 Bracket Unit CXB6083
75 Screw IMS20P030FMC
76 Chassis Unit CXB6477
77 Mechanism Assy(Service)CXX1487
78 Screw BMZ20P020FMC
79 Screw BMZ26P030FMC
80 Transistor(Q809,811,812) 2SB1185
81 Screw(M2x2) CBA1250
82 Spring CBH2472
83 Spring CBH2473
84 Spring CBH2478
85 Tube CDM1028
86 Chassis CNA2256
87 Case CNB2549
88 Holder CNC7477
89 Holder CNC7826
90 Holder CNC8701
(1) EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
NOTE:
- Parts marked by "*"are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to ∇ mark on the product are used for disassembly.
