Pioneer SC430 - Default Chapter; When the Repair Is Complete

FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
- See the page 81 of service manual FX-MG9006ZT/EW(CRT2539) for the SELF-DIAGNOSTIC FUNCTION.
FX-MG8156ZT/EW
- Supplementary model is identical to the original except for the addition of following items.
Description Part No.
FX-MG8156ZT-91/EW FX-MG8317ZT-91/EW
Polyethylene Bag CEG1026 CEG1026
Carton CHA3117 CHA3117
Contain Box CHD3117 CHD3117
Protector CHP2408 CHP2408
Protector CHP2409 CHP2409
Protector CHP2410 CHP2410
Protector CHP2411 CHP2411
Protector CHP2412 CHP2412
FX-MG8317ZT/EW
ID No.P3905
ID No.P3904
- This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
CX-631 CRT1640 2L
Cassette Mech. Module:Mech.Description, Disassembly
CX-890 CRT2376 G1 CD Mech. Module:Circuit Description, Mech.Description, Disassembly
Bup On, Acc OFF
SEEK/TRACK UP+
DISC(CD)+Acc ON
Display :
Display : SHIP
Bup OFF, Acc OFF
Shift completion to the transportation mode.
Disc loading slot illumination : Lighting
Disc loading slot illumination : Blinking
The mode is shifting to the transportation mode.
- When the Repair is Complete
When the repair is complete, make the CD mechanism ready for transportation.
