Pioneer SC430 - ELECTRICAL PARTS LIST; MISCELLANEOUS; RESISTORS; CAPACITORS

FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
5. ELECTRICAL PARTS LIST
NOTES:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
Unit Number : CWE1591
Unit Name : FM/AM Tuner Unit
MISCELLANEOUS
IC 1 IC PA4026A
IC 2 IC PA4024A
Q 1 Chip Transistor 2SC2712
Q 3 FET 3SK263
Q 31 Chip Transistor 2SC2712
Q 151 Transistor DTC144EU
Q 165 Transistor 2SC4116
Q 201 Transistor FC12
Q 203 Transistor DTC124EU
D 3 Diode 1SV251
D 4 Diode 1SV250
D 5 Diode KV1410-F1
D 6 Diode MA157
D 7 Diode KV1410-F1
D 8 Diode KV1410-F1
D 201 Diode MA157
D 202 Diode 1SV251
D 231 Diode SVC253
L 1 Inductor LCTBR12K2125
L 2 Coil CTC1145
L 3 Inductor LCTB4R7K2125
L 4 Coil CTC1131
L 5 Coil CTC1147
L 40 Inductor LCTBR15K1608
L 51 Ferri-Inductor LAU150K
L 52 Coil CTC1136
L 201 Ferri-Inductor LAU4R7K
L 202 Ferri-Inductor LAU330K
L 203 Inductor CTF1371
L 208 Inductor LAU390K
L 209 Ferri-Inductor LAU680K
L 210 Coil CTB1102
L 231 Inductor LAU3R3J
T 31 Coil CTE1116
TC 1 Trimmer CCL1046
CF 25 Ceramic Filter CTF1292
CF 51 Ceramic Filter CTF1292
CF 52 Ceramic Filter CTF1292
CF 53 Ceramic Filter CTF1292
CF 230 Crystal Filter CTF1262
CF 232 Ceramic Filter CTF1348
X 151 Radiator 918.5Hz CSS1365
X 231 Crystal Resonator 10.26MHz CSS1111
VR 101 Semi-fixed 15kΩ(B) CCP1230
VR 151 Semi-fixed 10kΩ(B) CCP1229
VR 154 Semi-fixed 150kΩ(B) CCP1236
VR 156 Semi-fixed 68kΩB) CCP1234
RESISTORS
R 3 RS1/16S223J
R 4 RS1/16S101J
R 5 RS1/16S151J
R 6 RS1/16S101J
R 7 RS1/10S331J
R 8 RS1/16S332J
R 9 RS1/16S473J
R 10 RS1/16S223J
R 11 RS1/16S124J
R 12 RS1/16S474J
R 15 RS1/16S271J
R 16 RS1/16S104J
R 17 RS1/16S332J
R 18 RS1/16S332J
R 19 RS1/16S154J
R 27 RS1/16S0R0J
R 31 RS1/16S470J
R 32 RS1/16S912J
R 33 RS1/16S912J
R 34 RS1/16S331J
R 35 RS1/16S331J
R 39 RS1/16S0R0J
R 51 RS1/16S331J
R 55 RS1/16S102J
R 56 RS1/16S823J
R 61 RS1/16S392J
R 62 RS1/16S393J
R 103 RS1/16S333J
R 104 RS1/16S334J
R 105 RS1/16S683J
R 107 RS1/16S222J
R 152 RS1/16S393J
R 155 RS1/16S393J
R 157 RS1/10S203J
R 160 RS1/16S222J
R 161 RS1/16S563J
R 162 RS1/16S225J
R 163 RS1/16S222J
R 164 RS1/16S563J
R 165 RS1/16S102J
R 202 RS1/16S223J
R 203 RS1/16S225J
R 204 RS1/16S103J
R 205 RS1/16S471J
R 206 RS1/16S220J
R 207 RS1/16S101J
R 208 RS1/16S102J
R 209 RS1/16S0R0J
R 214 RS1/16S563J
R 215 RS1/16S473J
R 217 RS1/16S393J
R 220 RS1/10S0R0J
R 231 RS1/16S242J
R 232 RS1/16S473J
R 233 RS1/16S0R0J
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
B
60
