FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
C 817 100µF/10V CCH1402
C 818 CKSQYB103K50
C 819 100µF/10V CCH1282
C 820 CKSQYB103K50
C 824 CKSQYB472K50
C 825 100µF/10V CCH1402
C 826 CKSQYB472K50
C 828 CKSQYB102K50
C 829 CKSQYB103K50
C 830 CKSQYB103K50
C 831 CKSQYB103K50
C 832 CKSQYB103K50
C 861 CKSQYB223K50
C 862 CKSQYB223K50
C 863 CKSQYB223K50
C 871 CKSQYB103K50
C 891 CKSQYB103K50
C 892 CKSQYB103K50
Unit Number : CWM7280
Unit Name : Control Unit
MISCELLANEOUS
IC 701 IC PD5673A
Q 701 Transistor DTA144EK
D 701 Diode 1SS355
L 701 Inductor LCTB100K3216
L 702 Inductor LCTB100K3216
TH 701 Thermistor CCX1036
X 701 Ceramic Resonator 6.290MHz CSS1367
RESISTORS
R 701 RS1/10S433J
R 702 RS1/10S103J
R 703 RS1/10S222J
R 704 RS1/8S103J
R 705 RS1/10S102J
R 706 RA2CQ222J
R 707 RA2CQ103J
R 708 330Ω CCN1116
R 709 RA2CQ222J
R 710 RS1/10S104J
R 711 RS1/10S331J
R 712 RS1/10S103J
R 713 RS1/10S102J
R 714 RA2CQ222J
R 715 RA2CQ103J
R 716 RA2CQ102J
R 717 RS1/10S102J
R 718 RS1/10S471J
R 719 RS1/10S102J
R 720 RA2CQ471J
R 721 RS1/10S102J
R 722 RA2CQ222J
R 723 RA2CQ473J
R 724 RS1/10S102J
R 725 RA3C471J
R 726 RA2CQ102J
R 727 RA2CQ102J
R 728 470Ω CCN1117
R 729 470Ω CCN1117
R 730 470Ω CCN1117
R 731 RS1/10S471J
R 732 RS1/10S912J
R 733 RS1/10S102J
R 734 2.2kΩ CCN1121
R 735 RS1/10S273J
R 736 RS1/10S512J
R 737 RS1/10S104J
R 738 RS1/10S154J
R 739 RS1/10S183J
R 740 RS1/10S102J
CAPACITORS
C 701 CKSYB102K50
C 702 CKSQYB102K50
C 704 CKSQYB102K50
C 705 CKSQYB102K50
C 706 CKSQYB102K50
C 709 CCSQCH101J50
C 711 CKSQYB102K50
C 712 CKSQYB102K50
C 714 CCSQCH180J50
C 715 CCSQCH180J50
C 716 CKSQYB102K50
C 717 CKSQYB102K50
C 718 CKSQYB102K50
C 719 CKSQYB102K50
C 721 CKSQYB102K50
C 722 CKSQYB105K10
C 723 CKSQYB103K50
C 724 CKSQYB102K50
C 725 CKSQYB102K50
C 726 CKSQYB102K50
C 727 CKSQYB102K50
C 728 CKSQYB102K50
Unit Number : CWS1333
Unit Name : Keyboard Unit
MISCELLANEOUS
IC 901 IC LC75804W
Q 901 Transistor 2SB1132
Q 902 Transistor DTC123YK
D 901 Chip LED NSCW310-0371
D 902 Chip LED NSCW310-0371
D 904 Chip LED NSCW310-0371
D 905 Chip LED NSCW310-0371
D 907 Diode DAP202K
D 908 Diode 1SS355
D 909 Diode 1SS355
D 910 Diode 1SS355
D 911 Diode 1SS355
D 912 Diode 1SS355
D 913 LED SML210FT
D 914 LED SML210FT
D 920 Diode HZU4R7(B3)
S 924 Switch(DCLOSE) CSN1051
IL 901 Lamp 8V 60mA CEL1685
IL 902 Lamp 8V 60mA CEL1685
IL 903 Lamp 8V 60mA CEL1686
IL 904 Lamp 8V 60mA CEL1686
IL 905 Lamp 8V 60mA CEL1686
IL 906 Lamp 8V 60mA CEL1686
IL 907 Lamp 8V 60mA CEL1685
IL 908 Lamp 8V 60mA CEL1685
IL 909 Lamp 8V 60mA CEL1685
IL 910 Lamp 8V 60mA CEL1685
IL 911 Lamp 8V 60mA CEL1685
IL 912 Lamp 8V 60mA CEL1685
IL 913 Lamp 8V 60mA CEL1685
IL 914 Lamp 8V 60mA CEL1685
VR 901 Encoder CSD1048
VR 902 Encoder CSD1065
LCD 901 LCD CAW1682
