Pioneer SC430 - Page 68

68
FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
C 116 CKSRYB682K50
C 117 CKSRYB333K16
C 118 CKSQYB334K16
C 119 CKSQYB334K16
C 120 CKSQYB334K16
C 121 CKSQYB334K16
C 122 CKSQYB104K16
C 123 CKSRYB472K50
C 124 CKSQYB104K16
C 125 CCSRCH5R0C50
C 126 CKSRYB153K25
C 127 CKSRYB102K50
C 201 CKSQYB334K16
C 202 CKSQYB104K16
C 203 CKSQYB104K16
C 204 CKSRYB471K50
C 207 CKSQYB683K16
C 208 CKSRYB821K50
C 209 CKSRYB273K25
C 210 CKSQYB334K16
C 211 CKSQYB334K16
C 212 CKSQYB334K16
C 213 10µF/10V CCH1349
C 301 CEV101M10
C 302 CEV101M10
Unit Number : CWX2422
Unit Name : CD Core Unit(STS Unit)
MISCELLANEOUS
IC 501 IC CXD2511R
IC 502 IC MSM514400DP-
60TS
IC 601 IC AK4321VF
IC 701 IC BA05SFP
IC 801 IC LB1836M
IC 802 IC LB1836M
Q 801 Transistor DTA123JK
Q 802 Transistor UN2211
D 701 Diode 1SR154-400
D 702 Diode 1SR154-400
D 703 Diode 1SS355
D 704 Diode 1SS355
D 705 Diode 1SS355
D 706 Diode 1SS355
D 707 Diode 1SS355
D 708 Diode 1SS355
S 801 Spring Switch(LOAD) CSN1052
S 802 Spring Switch(DOOR) CSN1052
S 803 Spring Switch(MODE) CSN1052
EF 701 Filter CCG1051
EF 702 Filter CCG1051
EF 703 Filter CCG1051
RESISTORS
R 501 RS1/16S102J
R 502 RS1/16S202J
R 503 RS1/16S392J
R 504 RS1/16S822J
R 505 RS1/16S163J
R 506 RS1/16S512J
R 507 RS1/16S182J
R 508 RS1/16S222J
R 509 RS1/16S102J
R 510 RS1/16S102J
R 511 RS1/16S102J
R 512 RS1/16S102J
R 513 RS1/16S102J
R 514 RS1/16S471J
R 601 RS1/16S101J
R 602 RS1/16S101J
R 603 RS1/16S471J
R 604 RS1/16S471J
R 702 RS1/10S100J
R 716 RS1/16S471J
R 717 RS1/16S471J
R 718 RS1/16S471J
R 801 RS1/10S102J
CAPACITORS
C 501 CKSQYB334K16
C 502 CKSQYB334K16
C 503 CKSQYB334K16
C 504 CCSRCH471J50
C 506 CCSRCH221J50
C 601 CKSQYB334K16
C 602 CCSRCH221J50
C 603 CKSQYB334K16
C 604 CKSQYB334K16
C 605 CSZSR100M10
C 606 CKSQYB334K16
C 701 10µF/10V CCH1349
C 702 CEVL101M6R3
C 703 CKSQYB334K16
C 704 CKSQYB334K16
C 705 CCSRCH151J50
C 706 CCSRCH151J50
C 707 CCSRCH151J50
C 801 CKSQYB104K25
C 802 CKSQYB104K25
C 803 CEVL220M16
Unit Number :
Unit Name : PCB Unit(A)
D 891 Chip LED CL205IRXTU
D 892 Chip LED CL205IRXTU
Unit Number :
Unit Name : PCB Unit(B)
S 886 Spring Switch(ELV Home) CSN1052
S 887 Spring Switch(Clamp) CSN1051
Unit Number :
Unit Name : PCB Unit(C)
Q 881 Photo-transistor CPT230SCTD
D 883 Chip LED CL205IRXTU
S 885 Spring Switch(MAX DETECT) CSN1052
L 801 Inductor LCYBR15J1608
L 802 Inductor LCYBR15J1608
Unit Number :
Unit Name : PCB Unit(D)
Q 851 Photo-transistor CPT230SCTD
Q 852 Photo-transistor CPT230SCTD
L 1 Inductor LCYBR15J1608
L 2 Inductor LCYBR15J1608
Unit Number :
Unit Name : PCB Unit(E)
R 856 RS1/8S911J
R 857 RS1/8S821J
Unit Number :
Unit Name : Motor PCB(A)
Q 1 Photo-interrupter RPI-221
M 1 Motor Unit(Cam Gear) CXB6929
M 3 Motor Unit(ELV) CXB3175
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
G
H
J
L
F
M
I
