Pioneer SC430 - CD MECHANISM SECTION PARTS LIST

FX-MG8156ZT,MG8156ZT-91,MG8317ZT,MG8317ZT-91
1-9 •••••
10 CD Core Unit(Servo Unit) CWX2421
11 Connector(CN101) CKS2764
12 Connector(CN301) CKS3966
13 Connector(CN201) CKS3991
14 CD Core Unit(STS Unit) CWX2422
15 Connector(CN701) CKS3989
16 Connector(CN801) CKS3989
17 Connector(CN802) CKS4054
18 Screw CBA1037
19 Screw CBA1041
20 Screw CBA1076
21 Screw CBA1250
22 Washer CBA1529
23 Screw CBA1452
24 Screw CBA1453
25 Screw CBA1479
26 Washer CBF1037
27 Washer CBF1038
28 Washer CBF1039
29 Washer CBF1064
30 Spring CBH2007
31 Spring CBH2271
32 Spring CBH2274
33 Spring CBH2014
34 Spring CBH2015
35 Spring CBH2016
36 Spring CBH2017
37 Spring CBH2290
38 Spring CBH2366
39 Spring CBH2064
40 Spring CBH2195
41 Spring CBH2196
42 Spring CBH2224
43 Spring CBH2250
44 Screw CBA1082
45 Roller CLA3154
46 Roller CLA3157
47 Roller CLA3159
48 Roller CLA3160
49 Shaft CLA3179
50 Spacer CLA3194
51 Roller CLA3248
52 Bush CLA3353
* 53 Shaft CLA3469
54 Shaft CLA3693
55 Steer CNC7215
56 Steer CNC7216
57 Cam CNC8774
58 Holder CNC7235
59 Gear CNC7236
60 Gear CNC9512
61 Lever CNC7243
62 Lever CNC7244
63 Lever CNC7245
64 Lever CXB4944
65 Cover CNC7441
66 Holder Unit CXB4946
67 Lever CNC9088
68 Gear CNC8140
69 Sheet CNM6840
70 PCB CNP5764
71 PCB CNP6010
72 Gear CNR1479
73 Gear CNR1481
74 Gear CNR1495
75 Gear CNR1501
76 Gear CNR1502
77 Gear CNR1540
78 Gear CNR1541
79 Belt CNT1080
80 Worm Gear CNV5046
81 Gear CNV5047
82 Gear CNV5048
83 Gear CNV5049
84 Holder CNV5056
85 Pulley CNV5058
86 Arm CNV5061
87 Spacer CNV5066
88 Arm CNV5189
89 Cover CNV5207
90 Cover CNV5424
91 Cover CNV5425
92 Lever CNV5427
93 Arm CNV5491
94 Gear CNV5519
95 Holder CNV5648
* 96 Composite PCB CNX3501
* 97 Composite PCB CNX3502
98 Chassis Unit CXB5940
99 Frame Unit CXB5806
100 Lever Unit CXB6026
101 Arm Unit CXB2704
102 Lever Unit CXB2708
103 Lever Unit CXB2709
104 Lever Unit CXB4949
105 Arm Unit CXB2712
106 Lever Unit CXB4948
107 Lever Unit CXB2714
108
Carriage Mechanism Unit(G1) CXB4941
- CD MECHANISM SECTION PARTS LIST
Mark No. Description Part No.
Mark No. Description Part No.
8
