Pioneer XV-E51 - Test Mode Operations; Test Mode Activation and Disc Setup; Test Mode Playback and Address Search; Test Mode Deactivation

XV-EV51
78
1234
1234
C
D
F
A
B
E
6.6 TEST MODE
TEST MODE: ON
TEST MODE: DISC SET
DSC - &&&
GGF1067
Test mode
remote control
unit
GGF1067
Test mode
remote control
unit
POWER
ON
<TRAY OPEN>
OPEN/CLOSE
(Player or Remote
Control Unit)
OPEN/CLOSE
(Player or Remote
Control Unit)
DVD disc
TEST MODE: PLAY
TEST MODE: OFF
An address is displayed
For example, when playback with # 30000
During PLAY
Press keys in order
OR
ESC
OFF
POWER
030000
<PLAY>
< When playback with the target address of disc (DVD)>
TV/LDP
+10 3 0 0 0 0 CHP/TIM
ESC TEST
CHECK
DVD, CD
CAUTION:
Perform only trace, video and audio output are
nothing.
Power Amplifier
Power Amplifier
DVD Tuner Deck
