EXTERIOR SECTION parts List
(2) CONTRAST TABLE
XV-EV51/ZLXJ/NC and XV-EV21/ZLXJ/NC are constructed the same except for the following :
Mark No. Description Part No.
1 FM/AM TUNER Module AXQ7228
2 IF Assy See Contrast table (2)
3 AF Assy See Contrast table (2)
4 DECK Assy See Contrast table (2)
5 DVDM Assy AWM7684
6 DVD IF Assy AWM7677
7 DSP Assy See Contrast table (2)
8 DECK Mechanism Unit XYM3015
NSP 9 LOADING MECHA Assy VWT1203
10 DC Fan Motor AXM7025
NSP 11 Earth Lead Wire DE012VF0
12 11P Flat Flexible Cable XDD3114
13 13P Flat Flexible Cable XDD3115
14 30P Flat Flexible Cable XDD3116
15 16P Flat Flexible Cable XDD3117
16 Connector Assy 5P XDE3055
NSP 17 Chassis XNA3011
18 Rear Panel A See Contrast table (2)
19 Rear Panel B See Contrast table (2)
20 Mecha Frame XNG3082
21 DVD Shield XNG3083
22 GND Plate XNG3084
23 Ratch Spring ABH7130
24 Damper Assy AXA7052
25 Door Spring L XBH3010
26 Leg Cushion XEB3028
27 Deck Lens XAK3327
28 Deck Door XAN3047
29 Ratch Mold XMR3001
30 Side Bonnet L XNE3026
31 Side Bonnet R XNE3027
32 Binder ZCA-SKB90BK
33 Tray Cap XAK3325
34 DVD Badge XAK3331
35 Top Panel XAK3326
NSP 36 Front Panel Assy See Contrast table (2)
NSP 37 Top Panel Assy XXG3131
38 Screw VPZ30P080FZK
39 Screw BBZ30P080FZK
40 Screw BBZ30P080FMC
41 Screw BPZ30P350FZK
42 Screw VPZ30P080FNI
43 Screw BBZ30P080FNI
44 Adapter 02 L ANW7247
45 Adapter 02 R ANW7248
46 Shield Case ANK7108
47 Heat plate ANG7426
48 Radiation Sheet AEB7255
49 Cushion AEB7267
50 FFC Barrier AEC7443
51 FFC Spacer AEC7442
52 Caution Label VRW1699
Mark
No. Description Part No.
Mark NO Symbol and Description
XV-EV51/ZLXJ/
NC
XV-EV21/ZLXJ/NC
2 IF Assy XWZ3617 XWZ3627
3 AF Assy XWZ3618 XWZ3628
4 DECK Assy XWX3067 XWX3066
7 DSP Assy AWX8059 Not used
18 Rear Panel A XNC3160 XNC3180
19 Rear Panel B XNC3161 XNC3176
NSP 37 Front Panel Assy XXG3129 XXG3130
