2-8 SV61831 Rev. A DA50S/DA55S/DA70S/DA75S AddressRight™ Printers Service Manual
2 • Specifications
2.5 Material
Specifications
Stacker Capacity
Input Stacker — DA50S/DA55S: 200 #10 or DL Envelopes; DA70S/DA75S:
600 #10 or DL Envelopes with Bin extension, or 250 without extension installed.
Output Stacker — DA50S/DA55S/DA70S/DA75S: 150 #10 or DL Envelopes
Approved Media
• Envelopes have a flap along the long edge and are processed by the
printer non-flap edge first. Envelopes may have either a diagonal or
straight edge along the envelope flap.
• Booklets are defined as media having physical dimensions 6 x 9”
(1523mm x 230mm) or larger. Booklets have an opening along their long
edge which is covered by a flap with an adhesive seal.
• Catalog envelopes have an opening along their short edge which is
closed by a flap with an adhesive seal.
• Postcards have no folds or bends. The printable side may have a higher
surface roughness than the non-printable side.
• Self-mailers may be of “C,” “Z,” or half-folded construction. They may not
exceed the maximum allowable thickness as specified on the previous
page and must be tabbed per postal regulations.
• A catalog may consist of multiple pages bound by adhesive or tabs on
the feed edge or at 90 degrees with respect to the feed edge.
• Sheet stock may consist of 16 to 28 lb. (60 to 105g/m
2
) bond as well as
60 to 80 lb. (220 to 300g/m
2
) coated stock. The size and thickness con-
straints specified above apply.
NOTE: The following materials should not be used:
• Contaminants – material with visible material loss (loose powder, ink, sur-
face glaze, etc.) when hung free over a clean surface and struck sharply
with a standard wood ruler
• NCR paper
• Special Materials – materials that are sensitive to heat such as thermal
papers, any pressure-sensitive materials, and materials that are sensitive
to minor magnetic fields.
