DA50S/DA55S/DA70S/DA75S AddressRight™ Printers Service Manual
4-15
Troubleshooting/Diagnostics • 4
4.5 Print
Samples for
Troubleshooting
The print samples below are provided to help troubleshoot printing problems
you may encounter.
Sample Print What It Indicates
Good printing
Poor printing due
to low ink (replace
ink cartridge)
Good test print
Smudging (need
to purge print
head)
A. Skew
B. Misfiring head
(missing points,
do purge print
head)
Table 4-8 Sample Prints
Figure 4-6 Sample Envelope Printed with a Variety of Options
All 3 versions of FIM
Barcode (USPS)
Postnet Barcode (USPS)
Return Address
