Pitney Bowes DA50S - Material Specifications

DA50S/DA55S/DA70S/DA75S AddressRight™ Printers Service Manual
2-7
Specifications • 2
For envelope addressing purposes, the printer is compatible with any word
processor or database application that can print a mailing label.
The paper types listed below are approved for use with the printer. Please note
that the dimensional limits above apply in all cases, and that all media (enve-
lopes, postcards, flats, etc.) must be without windows, unstuffed and unsealed.
• White Wove
• Bond paper
• Recycled paper
• Coated paper
• Card stock
• Brown kraft
• Manila
• Perforations
Refer to the table below for media size specifications.
Throughput
DA50S/DA55S: 10,000 letters per hour (lph)
DA70S/DA75S: 14,000 letters per hour (lph)
Based on:
• Print quality - Draft mode
• 3-line destination address
• 18 characters per line
• 12-point character size
• Time New Roman font
• Bidirectional printing of text
NOTE: Adding graphics and/or printing at a higher resolution (e.g., Letter or
Executive mode) will decrease throughput.
2.2 Print
Specifications
2.5 Material
Specifications
Media Sizes
DA50S DA55S DA70S DA75S
Min length 3.5" (89 mm) 3.5" (89 mm) 3.5" (89 mm) 3.5" (89 mm)
Max length 13.5" (343 mm) 13.5" (343 mm) 15.5" (394mm) 15.5" (394mm)
Min width 4.5" (114 mm) 4.5" (114 mm) 3.5" (89 mm) 3.5" (89 mm)
Max width 12.75" (324 mm) 12.75" (324 mm) 15" (381mm) 15" (381mm)
Min
thickness
0.003" (0.08 mm) 0.003" (0.08 mm) 0.003" (0.08 mm) 0.003" (0.08 mm)
Max
thickness
0.125" (3.175 mm) 0.125" (3.175 mm) 0.250" (6.35 mm) 0.250" (6.35 mm)
