12 - MODIFY CONFIGURATION PARAMETERS
The configuration menu of the unit is password protected to
prevent unauthorised access to the instrument set-up.
Password cannot be modified.
Press Display Do
1
After 5 seconds display
shows
, first digit
on the left is flashing.
on ATR141
2
Increase first digit to “1”
Press
to reach
following digit and
enter configuration
password “123” for
ATR121
or “1234” for ATR141
3
Display shows first
configuration parameter
for ATR121
for ATR141
4
The arrow-keys allow
the movement through
the configuration table
in both forward and
backward directions.
Select parameter to
modify, press
to
visualize it and use
arrow keys to modify
value.
