User manual - ATR142- 29
500
Loading default values:
9999 restore all values
9998 restore all values except for
baud-rate and slave address
9997 restore all values except for
slave address
9996 restore all values except for
baud-rate
WO 0
1000
Process (with tenths of degree for
temperature sensors; digits for
linear sensors)
RO -
1001 Setpoint1 R/W EEPROM
1002 Setpoint2 R/W EEPROM
1003 Setpoint3 R/W EEPROM
1004 Setpoint4 R/W EEPROM
1005 Alarm1 R/W EEPROM
1006 Alarm2 R/W EEPROM
1007 Setpoint gradient RO EEPROM
1008
Outputs status (0=off, 1=on)
Bit 0 = Q1 relay
Bit 1 = Q2 relay
Bit 2 = SSR
RO 0
1009
Heating output percentage
(0-10000)
RO 0
1010
Cooling output percentage
(0-10000)
RO 0
1011
Alarms status (0=none, 1=active)
Bit0 = Alarm 1
Bit1 = Alarm 2
RO 0
1012
Manual reset:
write 0 to reset all the alarms.
In reading
(0=not resettable, 1=resettable):
Bit0 = Alarm 1
Bit1 = Alarm 2
WO 0
