ATR401 - User manual 29
Modbus
address
Descrizione Read Write
Reset
value
1017
Start / Stop
0 = Controller in STOP
1 = Controller in START
R/W 0
1018
Lock conversion ON / OFF
0 = Lock conversion o
1 = Lock conversion on
R/W 0
1019
Tuning ON / OFF
0 = Tuning o
1 = Tuning on
R/W 0
1020
Automatic / Manual selection
0 = Automatic
1 = Manual
R/W 0
1021 OFF LINE* time (milliseconds) R/W -
1022
Digital input status
0 = Input OFF
1 = Input ON
RO -
1023 Instantaneous current value (tenth of ampere) RO 0
1024 Current ON value (tenth of ampere) RO 0
1025 Current OFF value (tenth of ampere) RO 0
1100 Process with decimal point selection RO -
1101 Setpoint 1 with decimal point selection R/W EEPROM
1102 Setpoint 2 with decimal point selection R/W EEPROM
1103 Setpoint 3 with decimal point selection R/W EEPROM
1104 Setpoint 4 with decimal point selection R/W EEPROM
1105 Alarm 1 with decimal point selection R/W EEPROM
1106 Alarm 2 with decimal point selection R/W EEPROM
1107 Alarm 3 with decimal point selection R/W EEPROM
1108 Alarm 4 with decimal point selection R/W EEPROM
1109
Real setpoint (gradient) with decimal point
selection
RO EEPROM
1110 Percentage heating output (0-1000) R/W 0
*
Se vale 0 il controllo è disabilitato. Se diverso da 0, è “Il tempo massimo che può trascorrere tra
due interrogazioni senza che il regolatore si porti in O -Line”. In O -Line il regolatore va in stato
di Stop.
