6 ATR401 - User manual
Introduction
Thanks for choosing a Pixsys controller.
The ATR401 integrates in a single device all options for sensors reading and
actuators control, beside extended range power supply 24…230 Vac/Vdc.
Thanks to dual universal analogue input and outputs con gurable as relay or
SSR, the user or the retailer can reduce stock needs.
The series includes also a model with serial communication RS485/
Modbus-RTU and analogue output 0-10 V, 0/4-20 mA.
The possibility to copy parameterization is simpli ed by the Memory Cards
with internal battery that do not require power supply for the controller.
1 Model Identi cation
ATR401 series includes  ve versions.
Looking at the following table it is possible to  nd the required model.
Power supply 24…230 Vac/Vdc +/-15% 50/60 Hz – 5,5 VA
ATR401-22ABC 2 Analogue inputs + 2 Relays 8 A + 1 SSR + D.I.
ATR401-23ABC 2 Analogue inputs + 3 Relays 8 A + 1 SSR + D.I.
ATR401-24ABC 2 Analogue inputs + 4 Relays 8 A + 1 SSR + D.I.
ATR401-22ABC-T
2 Analogue inputs + 2 Relays 8 A + 1 SSR
1 Output V / mA + RS485
ATR401-22ABC-D
2 Analogue inputs + 2 Relays 8 A + 1 SSR
1 Output V / mA + D.I.
2 Technical data
2.1 General data
Indicators 4 display 0,40 inches - 4 display 0,30 inches
Operating
temperature
Temperature 0-45 °C - Humidity 35..95 uR%
Sealing
Front panel IP54 (IP65 with gasket), box IP30 , terminal
blocks IP20
Material
Box: Noryl UL94V1 self-exstinguish
Front panel: PC ABS UL94V0 self-exstinguish
Weight Approx 350 g
