44  Alarm 1 Delay
-600…+600 seconds.
Negative: delay at exit from alarm.
Positive: delay at starting of alarm.
Default: 0.
45  Alarm 1 Setpoint Protection
Alarm 1 set protection. Does not allow the user to change setpoint
 Modi cation allowed (Default)
  Protected
   Protected and not visualized
46  Alarm 2
Alarm 2 selection. Alarm intervention is associated to AL2
dis. Disabled (Default)
  Absolute alarm, referring to process
  Band alarm
   Upper deviation alarm
     Lower deviation alarm
 Absolute alarm, referring to command setpoint
 Status alarm (active in Run / Start)
 Cooling action
   Load control alarm (Heater Break Alarm)
     Sensor failure alarm (Loop Break Alarm)
-Example: status of contactor/ SSR or heating elements
47  Alarm 2 Process
Selects value related to alarm 2
 Process 1 (Default)
 Process 2
 Processes mean
   Processes di erence
 Processes di erence as absolute value
 AI1+AI2 Input addition
48  Alarm 2 State Output
Alarm 2 output contact and type of action
 (N.O. start) Normally open, active from Start (Default)
   (N.C. start) Normally closed, active from Start
