44 ATR401 - User manual
59  Alarm 3 Rearmament
Type of reset for alarm 3 contact
 Automatic Reset (Default)
 Manual Reset by keyboard
 Manual reset stored. (keeps relay status also after an eventual
power failure)
60  Alarm 3 State Error
Contact status for alarm 3 output in case of error
  Open contact (Default)
  Closed contact
61  Alarm 3 Led
De nes led A3 status corresponding to relevant contact
  ON with open contact
  ON with closed contact (Default)
62  Alarm 3 Delay
-600…+600 seconds.
Negative: delay at exit from alarm.
Positive: delay at starting of alarm.
Default: 0.
63  Alarm 3 Setpoint Protection
Alarm 3 set protection. Does not allow the user to change set value
 Modi cation allowed (Default)
  Protected
   Protected and not visualized
64  Alarm 4
Alarm 4 selection. Alarm intervention is associated to AL4
   Disabled (Default)
  Absolute alarm, referring to process
  Band alarm
   Upper deviation alarm
     Lower deviation alarm
 Absolute alarm, referring to command setpoint
 Status alarm (active in Run / Start)
 Cooling action
