ATR 621 - User manual 39
38  Recovery Interrupted Cycle
Enables interrupted cycle recovery function.
0 Cycle recovery disabled
1 Cycle recovery enabled with automatic gradient > Default.
2…9999 [digit
4
]. Select recovery gradient (rising).
43  Valve Time
Time for open/close servo-valve (value declared by servo-valve manu-
facturer). Not allowed for feedback valves (potentiometer).
0…300 seconds. > Default: 60.
45  Alarm 1
Alarm 1 selection.
 (Disabled). > Default.
 (Absolute Alarm). Absolute Alarm, referring to the process.
 (Band Alarm). Command sepoint ± band.
 (High Deviation Alarm). Command setpoint + deviation.
  (Low Deviation Alarm). Command setpoint - deviation.
(Absolute Command Setpoint Alarm). Re erring to the sepoint.
 (Start Alarm). Active in RUN.
 (End Alarm). Active at cycle end.
(Auxiliary Output Related to the Step). ON/OFF at each step.
(Auxiliary Output Rising Maintenance). Auxiliary output active
for rising and holding steps.
(Auxiliary Output Falling). Auxiliary output active for falling
steps.
 (Cooling). Actuator output for cooling during double loop
functioning.
46  Alarm 1 State Output
Selects contact type for alarm 1 output.
 (Normally Open ). > Default.
 (Normally Closed).
47  Alarm 1 Threshold
Selects setpoint value for alarm 1.
-999+9999 [digit
4
] (degrees.tenths for temperature sensors). > Default: 0
