Special functions
33
 
Hold function
34
  
Number of cycles availables for the user
35

Number of cycles which cannot be programmed
by the user
36

End step waiting time
37

Max. gap for end step waiting
38
  
Interrupted cycle recovery
43

Time for servo-valve opening/closure
45

Alarm 1 selection
46

Alarm 1 output contact type
47

Alarm 1 setpoint value
48

Alarm 1 hysteresis
49

Alarm 1 output contact status in case of error
50

Led A1 ON status
51

Alarm 1 action type on operating cycle
52

Alarm 2 selection
53

Alarm 2output contact type
54

Alarm 2 setpoint value
55

Alarm 2 hysteresis
56

Alarm 2 output contact status in case of error
57

Led A2 ON status
58

Alarm 2 action type on operating cycle
59

Alarm 3 selection
60

Alarm 3 output contact type
61

Alarm 3 setpoint value
62

Alarm 3 hysteresis
63

Alarm 3 output contact status in case of error
64

Led A3 ON status
65

Alarm 3 action type on operating cycle
73
 
Cooling  uid type
74
    
Proportional band multipler
75

Overlap/Dead band
76

Cooling output cycle time
77
 
Remote setpoint mode
78

Baud rate
79

Data format for serial communication
80
 
Slave address
