Planar EP5024K - Page 33

Picture Menu
28 EP Series Ultra HD LCD Displays User Guide
Hue
Increase or decrease the green hue. Press e or f to select the desired level.
Range: 0~100; Default: 50
Note: This function is not available when displaying PC or graphics sources
Saturation
Adjust the brilliance and brightness. Press e or f to select the desired level.
Range: 0~100; Default: 50
Note: This function is not available when displaying PC or graphics sources
Backlight
Increase or decrease the intensity of the LCD backlight. Press e or f to select the
desired level.
Range: 0~100
Default: 80
Color Temp and Gamma
Select gamma
Options: Off, 1.85, 1.9, 1.95, 2.0, 2.05, 2.10, 2.15, 2.2, 2.25, 2.3, 2.35, 2.4, 2.45, 2.5, 2.55, 2.6
Default: 2.2
Select color temperature
Options: User, 3200K, 5000K, 6500K, 7500K, 9300K
Default: 9300K
RGB Range
Select RGB range for HDMI and DisplayPort sources
Options: Auto, Full, Limited
Default: Auto
