PLANET ECLIPSE GEO 4 - Tournament Lock; Battery Indicator

FIG-1
A
B
13
FIG-1
The Lock Indicator
A
shows the status of the Tournament Lock (see page 17).
Locked
Firing mode parameters cannot be changed. Tournament legal state.
Unlocked
Firing mode parameters can be changed.
The Battery Indicator
The Battery Indicator
B
shows the level of charge the battery has.
Full battery
The battery is fully charged.
Drained battery
Battery is at approximately 50% of useful charge.
Battery circuit fault
The battery level cannot be determined.
Estimated battery
The battery level cannot be determined until the marker is red.
INTRODUCTION
TOURNAMENT LOCK /
BATTERY INDICATOR
