PLANET ECLIPSE GEO 4 - Switching the Marker On and Off

FIG-1
B
D
C
A
08
FIG-1
The navigation console houses the LCD screen
A
and the navigation
buttons: Up
B
Down
C
and Select
D
.
Use the navigation console to switch the GEO 4 On or O and change
the marker settings.
Switching ON
Press and hold the Select button
D
– or double-click it
1
– until the
Eclipse logo is displayed.
Switching OFF
Press and hold the Select button
D
– or double-click it
1
– until the TURN
OFF option is displayed. Press the Select button again once to switch o.
Firing the marker
Pull the trigger to re the marker. The breech sensor (BS) will indicate
whether the marker is able to re.
To switch the breech sensor ON/OFF push and hold
B
for 0.5 seconds
when the marker is switched on. See page 10 for BS indicator details.
1 The double-click feature can be disabled in the HARDWARE menu (see page 35).
INTRODUCTION
SWITCHING ON/OFF
WARNING!
DO NOT dry re your marker as this may lead to damage over a sustained
period of dry ring.
WARNING
