ELECTRONICS
USER INTERFACE
FIG-1
The marker can be congured through editable
parameters that are arranged in a menu system.
To access the menu when the marker is on, push
and hold the Select button until the TURN OFF
menu item is displayed. Double-clicking will also
access the menu if enabled. See page 35.
The top level menu shown opposite is comprised
of a number of sub-menus and a number of
editable parameters.
Some parameters aect the way the marker
shoots. These parameters can only be modied
when the tournament lock is o. See page 17.
The availability of some parameters and sub-
menus is dependent upon the setting of other
parameters (e.g. the RAMP SETUP menu is only
available when the FIRE MODE is set to RAMP).
Select EXIT to return to the previous menu level,
or – if already on the top level – to leave the
menu system.
Select TURN OFF to turn o the marker.
The layout and parameters shown in this manual are correct at
the time of printing.
