INTRODUCTION
THE TOURNAMENT
LOCK BUTTON
FIG-1
To access the tournament lock button push the grip release tabs (both
sides)
A
towards the front of the frame to release the rear grip section
B
then simply pull and remove the rear grip.
FIG-2
Open and remove the front grip section
C
.
FIG-3
You can now locate the tournament lock button
D
.
FIG-4
Push the tournament lock button
E
to toggle the tournament lock
state – which will be displayed on the LCD. See page 13 for more.
Replace the rubber grips as per FIG-1 and FIG-2.
WARNING!
Always ensure the marker is made safe before changing the tournament lock
state to avoid accidentally ring the marker.
