INSTALLING THE BATTERIES
The GEO 4 uses 2 x AA (LR6, 1.5V) batteries situated in the foregrip.
Switch the marker o before you begin.
FIG-1
Pull the foregrip
A
away from the body to expose the battery holder
B
.
FIG-2 / FIG-3
Insert two new AA batteries
C
and
D
in either side of the battery holder
with the battery terminals in the correct orientation.
Replace the rubber foregrip as per FIG-1.
1
ALWAYS pull in a straight, downwards motion NOT at an angle or
with a twist.
2
DO NOT use poor quality batteries.
