PLANET ECLIPSE GEO CS1 - Quick Start: Velocity Adjustment

FIG-1
10
GEO:CS1
QUICK START
VELOCITY ADJUSTMENT
FIG-1
The CS1 velocity adjustment screw is accessed from the underside of
the POPS bonnet.
With the POPS bonnet in the rear (engaged) position, insert a 1/8
hex key
A
into the velocity adjuster screw
B
to adjust the velocity
of the CS1.
1
Turn the hex key clockwise to reduce velocity.
2
Turn the hex key counter-clockwise to increase velocity.
3
Fire two clearing shots after each velocity adjustment for an
accurate velocity reading.
1
DO NOT turn the adjuster screw in too far. This will prevent the
CS1 from ring.
WARNING!
DO NOT exceed 300FPS.
Always wear correct protective equipment when ring your marker.
NEVER leave the CS1 gassed up when unloading.
NEVER point your marker in the direction of other people when not on the eld.
WARNING
–
+
1
B
A
HEX
1/8
