PLANET ECLIPSE GEO CS1 - Electronics: Breech Sensor (BS) Indicator

FIG-1
18
GEO:CS1
ELECTRONICS
BREECH SENSOR (BS) INDICATOR
FIG-1
The BS indicator
A
displays the various states of the breech sensor.
BS enabled and a ball is detected
The CS1 can be red at the maximum ring mode Selected.
BS fault has been cleared and a ball is detected
The CS1 can be red at the maximum ring mode Selected.
BS disabled
The CS1 can be red at the BS OFF ROF setting (page 18).
BS enabled in training mode
CS1 training mode is enabled and simulates ring at the
maximum ring mode Selected with BS On.
BS enabled and NO ball is detected
The CS1 cannot be red.
BS fault has been cleared and NO ball is detected
The CS1 cannot be red. Use the Up button to switch the BS
o then on again.
BS fault detected
System is disabled. The CS1 can be red at 2 bps less than
the max ROF - limited to 10 bps max.
BS enabled in training mode
CS1 training mode is enabled and simulates ring at the
maximum ring mode Selected with BS O.
A
