GEO:CS1
TECHNICAL INFORMATION
PUSH ON PURGE SYSTEM (POPS) ASSEMBLY
POPS pin
#005 NBR90
#004 NBR70
#004 NBR70
Latch springPOPS bonnet Latch button
#007 NBR70
Insert
Pin
