Planet VC-201A User Manual

10
1.3 Key Features
The Ethernet Over VDSL2 Converter provides the following key
features:
Cost-effective VDSL2 CO / CPE bridge solution
One box design, CO / CPE selectable via DIP Switch
Denes Asymmetric (Band Plan 998) and Symmetric band
plans for the transmission of Upstream and Downstream
signals
Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x
standards
DMT (Discrete Multi-Tone) line coding
Half Duplex Back Pressure and IEEE 802.3x Full Duplex Pause
Frame Flow Control
Built-in POTS splitter to share voice and data - (VC-201A
and VC-204)
Voice and data communication can be shared on the existing
telephone wire simultaneously - (VC-201A and VC-204)
Support up to 1536 bytes packet size, 802.1Q VLAN tag
transparent
VDSL2 Stand-Alone transceiver for simple bridge modem
application
Selectable Target Band Plan and Target SNR Margin
Support extensive LED indicators for network diagnostics
l
l
l
l
l
l
l
l
l
l
l
l

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
