3. Installation
3.1 Install Ethernet over VDSL2 Converter
The Ethernet over VDSL2 Converter does not require any
software conguration. Users can immediately use any feature
of this product simply by attached the cables and plug power
on. There is some key limitation on the Ethernet over VDSL2
Converter. Please check the following items:
VC-201A and VC-204: The device is used for Point-to-Point
connection only (Master device to Slave device) and has
equipped with 2 RJ-11 connectors for VDSL port. One for
voice device connection (like telephone) and the other one for
network link connection.
Depending on the quality of telephone line, the maximum
distance of one VDSL segment is 1.6km (5250ft) with AWG
24 telephone wires.
VC-202A: 1 BNC connector and supports 50 or 75 ohm cable.
Depending on the quality of coaxial cable, the maximum
distance of one VDSL segment is 3.0km (9842ft) with 5C
coaxial cable.
The distance will change by the quality of telephone wires and
coaxial cables.
l
l

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
